[C#/UWP] MenuBar 엘리먼트 : 하위 메뉴, 분리자, 라디오 항목 사용하기

TestProject.zip

0.02MB

▶ MainPage.xaml

<Page x:Class="TestProject.MainPage"
    xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
    xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
    xmlns:muxc="using:Microsoft.UI.Xaml.Controls"
    Background="{ThemeResource ApplicationPageBackgroundThemeBrush}"
    FontFamily="나눔고딕코딩"
    FontSize="16">
    <Grid>
        <StackPanel
            HorizontalAlignment="Center"
            VerticalAlignment="Center"
            Spacing="10">
            <TextBlock Name="textBlock"
                HorizontalAlignment="Center"
                Text="" />
            <muxc:MenuBar>
                <muxc:MenuBarItem Title="파일">
                    <MenuFlyoutSubItem Text="새 파일">
                        <MenuFlyoutItem Text="텍스트 문서" Click="menuFlyoutItem_Click" />
                        <MenuFlyoutItem Text="RTF 문서"    Click="menuFlyoutItem_Click" />
                        <MenuFlyoutItem Text="다른 포맷"   Click="menuFlyoutItem_Click" />
                    </MenuFlyoutSubItem>
                    <MenuFlyoutItem Text="파일 열기" Click="menuFlyoutItem_Click" />
                    <MenuFlyoutItem Text="저장"      Click="menuFlyoutItem_Click" />
                    <MenuFlyoutSeparator />
                    <MenuFlyoutItem Text="종료"      Click="menuFlyoutItem_Click" />
                </muxc:MenuBarItem>
                <muxc:MenuBarItem Title="편집">
                    <MenuFlyoutItem Text="실행 취소" Click="menuFlyoutItem_Click" />
                    <MenuFlyoutItem Text="잘라내기"  Click="menuFlyoutItem_Click" />
                    <MenuFlyoutItem Text="복사하기"  Click="menuFlyoutItem_Click" />
                    <MenuFlyoutItem Text="붙여넣기"  Click="menuFlyoutItem_Click" />
                </muxc:MenuBarItem>
                <muxc:MenuBarItem Title="보기">
                    <MenuFlyoutItem Text="출력" Click="menuFlyoutItem_Click" />
                    <MenuFlyoutSeparator />
                    <muxc:RadioMenuFlyoutItem
                        GroupName="OrientationGroup"
                        Text="가로"
                        Click="menuFlyoutItem_Click" />
                    <muxc:RadioMenuFlyoutItem
                        GroupName="OrientationGroup"
                        Text="세로"
                        IsChecked="True"
                        Click="menuFlyoutItem_Click" />
                    <MenuFlyoutSeparator />
                    <muxc:RadioMenuFlyoutItem
                        GroupName="SizeGroup"
                        Text="작은 아이콘"
                        Click="menuFlyoutItem_Click" />
                    <muxc:RadioMenuFlyoutItem
                        GroupName="SizeGroup"
                        Text="중간 아이콘"
                        IsChecked="True"
                        Click="menuFlyoutItem_Click" />
                    <muxc:RadioMenuFlyoutItem
                        GroupName="SizeGroup"
                        Text="큰 아이콘"
                        Click="menuFlyoutItem_Click" />
                </muxc:MenuBarItem>
                <muxc:MenuBarItem Title="도움말">
                    <MenuFlyoutItem Text="정보"
                        Click="menuFlyoutItem_Click" />
                </muxc:MenuBarItem>
            </muxc:MenuBar>
        </StackPanel>
    </Grid>
</Page>



728x90



▶ MainPage.xaml.cs

using Windows.Foundation;
using Windows.Graphics.Display;
using Windows.UI.ViewManagement;
using Windows.UI.Xaml;
using Windows.UI.Xaml.Controls;

namespace TestProject
{
    /// <summary>
    /// 메인 페이지
    /// </summary>
    public sealed partial class MainPage : Page
    {
        //////////////////////////////////////////////////////////////////////////////////////////////////// Constructor
        ////////////////////////////////////////////////////////////////////////////////////////// Public

        #region 생성자 - MainPage()

        /// <summary>
        /// 생성자
        /// </summary>
        public MainPage()
        {
            InitializeComponent();

            #region 윈도우 크기를 설정한다.

            double width  = 800d;
            double height = 600d;

            double dpi = (double)DisplayInformation.GetForCurrentView().LogicalDpi;

            ApplicationView.PreferredLaunchWindowingMode = ApplicationViewWindowingMode.PreferredLaunchViewSize;

            Size windowSize = new Size(width * 96d / dpi, height * 96d / dpi);

            ApplicationView.PreferredLaunchViewSize = windowSize;

            Window.Current.Activate();

            ApplicationView.GetForCurrentView().TryResizeView(windowSize);

            #endregion
            #region 윈도우 제목을 설정한다.

            ApplicationView.GetForCurrentView().Title = "MenuBar 엘리먼트 : 하위 메뉴, 분리자, 라디오 항목 사용하기";

            #endregion
        }

        #endregion

        //////////////////////////////////////////////////////////////////////////////////////////////////// Method
        ////////////////////////////////////////////////////////////////////////////////////////// Private

        #region 메뉴 플라이아웃 항목 클릭시 처리하기 - menuFlyoutItem_Click(sender, e)

        /// <summary>
        /// 메뉴 플라이아웃 항목 클릭시 처리하기
        /// </summary>
        /// <param name="sender">이벤트 발생자</param>
        /// <param name="e">이벤트 인자</param>
        private void menuFlyoutItem_Click(object sender, RoutedEventArgs e)
        {
            MenuFlyoutItem menuFlyoutItem = sender as MenuFlyoutItem;

            this.textBlock.Text = $"메뉴를 클릭했습니다 : {menuFlyoutItem.Text}";
        }

        #endregion
    }
}
